Note: to use the new Stabicad Flexible Pipes feature, you’ll need at least Stabicad for Revit version 11.02. Report the total length of the pipes with a schedule.Connect plumbing fixtures and radiators at once.Tees and reducers are automatically placed.Flexibles will no longer slow down your projects.Sanitary appliances and radiators can be connected to piping systems at once using the node solver and the Revit function 'connect into'. In addition, flexible drawing now also works vertically, in elevation views. And you can calculate the total length of pipes select a part of the system or choose your entire system, and report the total length of the pipes with a schedule. You can override the bend radius to smoothen the path of the system. The smart PLS files (product line sheets with all relevant data) also contain Stabicad Autorouting, which automatically places tees and reducers. But there is more within this new, powerful feature. Modelling with flexible pipes becomes as easy as drawing with rigid, non-flexible, systems. The path of the system can be changed without affecting the other parts. With Stabicad Flexible Pipes, Stabiplan introduces a completely new way of drawing flexible pipe systems for water and central heating. Fortunately this is over with the new feature: Stabicad Flexible Pipes! It is by all means one of the most heard annoyances of modeling in Revit. It's a time consuming job that usually results in pipes moving in all directions except the one you want. ActCAD Nesting - ActCAD Dials & Scales - ActCAD CNC Post Processor ActCAD uses the latest IntelliCAD 11.1 Engine, Open Design Alliance, dwg/dxf Libraries, ACIS 3D Modeling. Anyone who has ever tried to draw flexible pipes in Revit knows that this can lead to great frustrations. Compare price, features, and reviews of the software side-by-side to make the best choice for your business.
